GREE Air-ccoled Closed Control Unit Service Manual
125
22
Electric Heater 32105200001
1
23
Evaporator Assy 011001000069
1
24
Pressure difference switch sub-assy 2 '46028000001
1
25
Centrifugal Fan sub-assy 150184042
1
26
Terminal Board '42010052
1
27
Electric Box Assy ‘100002000146
1
◆ Parts' list of JKFD15CR/Na-M(I)
Compared with model JKFD15QSR/Na-M(I)
，it just add false ogive. So please refer to parts list
of model JKFD15QSR/Na-M(I).
◆ Parts’ list of JKFD20QSR/Na-M(I)
No. Part Name Material Code Q’ty
1
Display Board 300001000009
1
2
Thick Filter 710024000005
1
3
Electromagnetic water valve '43042800025
1
4
Magnet Coil (electromagnetic valve) '43042800026
1
5
Humidifier Assy 000156000002
1
6
Detecting plate '30270005
1
7
Water Immersion Switch '45020501
1
8
pressure difference switch '46028251
1
9
Temp Sensor Sleeving '05210001
1
10
Compressor and Fittings 0020223101
1
11
Pressure Protect Switch '4602001559
1
12
Nozzle for Adding Freon '06120016
1
13
Pressure Protect Switch 46020015104
1
14
Gas-liquid Separator '07424146
1
15
Square Valve '07334103
1
16
Square Valve '07130128
1
17
Temp Sensor Sleeving '05212423
1
18
Electronic Expansion Valve '43044100173
1
19
Electric Expand Valve Fitting '4304413228
1
20
Strainer '07213051
1
21
Temperature Limiter '46010520
1
22
Electric Heater 3210521510
1
23
Evaporator Assy 011001000069
1
24
Pressure difference switch sub-assy 2 '46028000001
1
25
Centrifugal Fan sub-assy '150184066
1
26
Terminal Board '42010052
1
27
Electric Box Assy 100002000139
1
