GREE Air-ccoled Closed Control Unit Service Manual
10
H
mm 1130
Net Weight
kg 136
Conne
ction
pipe
Liquid Refrigerant Pipe mm×pcs
Φ16×1
Gas Refrigerant Pipe mm×pcs
Φ19×1
Method of Connection Flared-fitting Joint
Form 5
Class Item
Model
Unit
JKFD25C2/Na-M JKFD25QS2/Na-M JKFD25SX2/Na-M
Code of Product EJ13000400 EJ13000320 EJ13000350
Characteristics of Units
Total Cooling Capacity /
Sensible Cooling
Capacity(22℃/50%)
kW 26.5/23.8
Total Cooling Capacity /
Sensible Cooling
Capacity(24℃/17℃)
kW 27.0/24.3
Total Cooling Capacity /
Sensible Cooling
Capacity(24℃/45%)
kW 26.8/24.0
Total Cooling Capacity /
Sensible Cooling
Capacity(26℃/50%)
kW 27.6/24.5
Heating Capacity kW 12
Rated Humidifying
Capacity
kg/h 8
Air Flow Volume m
3
/h 7800 7500 7500
External Static Pressure Pa 0 100 100
Acoustic Noise of Indoor
Units
dB(A) 66 68 68
Range of Temp. Controlling and
Precision
17～28℃±1℃
Range of Humidity and Precision 40～60%±5%
Power Supply 380V 3N～ 50Hz
Coolin
g
Syste
m
Compressor Type Hermetic Scroll Type
Evaporator Type Inner Screw Thread Pipe with Hydrophilic Film Aluminum Fin
Condenser Type Inner Screw Thread Pipe with Hydrophilic Film Aluminum Fin
Refrigerant R410A
Throttling Method Electronic Expansion Valve
Air
Supply
Syste
m
Indoor Unit
Fan
Type Low Noise and Centrifugal External-rotor
Type of
Direct Drive
Air Filter Type Plate Filter (G4)
Heatin
g
S
y
ste
Heater Type Electric Heating
Humidi
fying
Syste
Humidifier
Type
Electrode Type
Control Mode
Automatic Control by Mainboard
Indoor
Unit
Indoor Unit Model
JKFD25C2/Na-M(I) JKFD25QS2/Na-M(I) JKFD25SX2/Na-M(I)
Dimension
W mm
1900 1900 1900
D mm
810 810 810
H mm
2250 1950 1950
Net Weight kg
585 570 535
Outdoo
r Unit
Outdoor Unit Model
JKFD13/NaA-M(O)
Qty Set
2
Condensing
Fan
Type Low Noise Axial Type
Type of Drive Direct Drive
Noise dB(A) 64
Dimension
W mm
1080
