GREE Air-ccoled Closed Control Unit Service Manual
133
◆ Parts' list of JKFD40SX2/Na-M(I)
No. Part Name Material Code Q’ty
1 Pressure difference switch1 01325236 1
2 Centrifugal fan SYB-355II(1.5-6) 15703707 2
3 Mounting plate of electric part 01323764 1
4 Electric control door 01393753P 1
5
Electric heater BKR
9000W/380V
32103703 2
6 Soleplate 2 of evaporator 01093736P 1
7 Touch screen ZE130 35018017 1
8 Panel 01543799 3
9 Middle and right panel 01543798 1
10 Cross beam 01873783P 2
11 Pressure difference switch2 01325237 1
12 Lower longitudinal beam 01873781 1
13 Evaporator 01023720 1
14 Upper column 01853744P 4
15 Left panel 01543858 1
16 Column 01853738 2
17 Cross beam(strainer) 01873790P 2
18 Upper longitudinal beam 01873782 1
19 Longitudinal beam(strainer) 01873789P 2
20 Primary strainer assy 07413708 3
21 Top panel 01263733 1
22 Midddle panel 01643701 2
23
Connection pipe sub-assy1
（air-return pipe）
05023745 1
24
Connection pipe 2(air-return
pipe)
05023747 1
25 Soleplate 1 of evaporator 01093734P 1
26
Compressor and fittings
ZP83KCE-TFD-522
00202231 2
27 Rear electric control plate 02223766 1
28 Hot gas bypass valve sub-assy - 2
29 Discharge pipe2 04633731 1
30 Isolation sheet 01243734P 1
31 Column sub-assy (right rear) 01853740P 1
32 Right door plate 02223764P 1
33 Air-return pipe2 04673739 1
34 Electronic expansion valve 2 07333714 1
35 Connection pipe sub-assy 1 05023756 1
36 Electronic expansion valve 1 07333713 1
37 Fixing beam 3 01873786P 1
To Next Page
