The relative equivalent length of elbow and oil loop
Outside Diameter of
Connecting Pipe(mm)
Elbow (m)
Oil Loop (m)
Ф9.52 0.2 1.4
Ф12 0.25 1.8
Ф16 0.3 2
Ф19 0.35 2.4
Ф22 0.4 2.8
Note: The equivalent pipe length equals the length of straight pipe plus the equivalent length of
elbow and oil loop.
