Gree JKFD7CR/Na-M

GREE Air-ccoled Closed Control Unit Service Manual
21
◆Outline Dimension of Indoor Units of JKFD40 Series (Bottom Air Outlet)
810
2480
1950
Back SideFront Side
Right Side
6.2.2 Outdoor Unit
◆ Outline Dimensions of JKFD5P/Na-E(O) and JKFD7P/Na-E(O)
(The picture is for a reference only and the actual item is the standard. Unit: mm)
