GREE Air-ccoled Closed Control Unit Service Manual
25
6.3.2 Installation of Outdoor Unit
◆ Disassembly of Outdoor Unit
Local Room of
Components
M6 (24 sets)
Nut with Washer
M6 (16)
Support Leg (4)
Bracket (4)
Disassembly Diagram of Horizontal Installation
Disassembly Diagram of Vertical Installation
