OPERATION SECTION FOR
KWCA/K1CA09/12 & KWHA/K1HA09/12
Guide to features and their function
There are many models, features and appearance will vary. The figure shown is
representative of the operation of 9,000/12,000 Btuh systems.
OPERATION AND MAINTENANCE SECTION FOR KWCA/ K1CA18/24 & KWHA/K1HA18/24 model follows this section.
Air return grill
Takes in the indoor air
Push down the air inlet grille and the push both sides of air inlet
Lightly push both sides of the air inlet grille at the
botton and pull it to this side till a resistance is felt.
Note: Do not open the grille at an angle over 60 degrees.
grille at the bottom.
