43
Installation and Maintenance
Service Manual
Steps Procedure
5HPRYHWKHVFUHZV¿[LQJWRSFRYHUSDQHODQGOHIW
right side plate, to remove top cover.
5HPRYHWKHVFUHZV¿[LQJJULOOHDQGSDQHOWRUHPRYH
the grille on the panel.
5HPRYHWKHVFUHZV¿[LQJSDQHOFKDVVLVDQGPRWRU
support, to remove the panel.
2.Remove top cover
3.Remove grille
4.Remove panel
top cover
grille
panel
