44
Installation and Maintenance
Service Manual
Steps Procedure
5HPRYHWKHVFUHZV¿[LQJULJKWVLGHSODWHYDOYH
support and guard grille, to remove the right side
plate.
5HPRYHWKHVFUHZV¿[LQJJXDUGJULOOHDQGOHIWVLGH
plate to remove guard grille.
5HPRYHWKHVFUHZV¿[LQJFKDVVLVDQGFRQGHQVHU
support, to remove the left side plate.
5.Remove right side plate
6.Remove guard grille
7.Remove left side plate
right side plate
guard grille
left side plate
