45
Installation and Maintenance
Service Manual
Steps Procedure
5HPRYHWKHVFUHZV¿[LQJVXSSRUWDQGFKDVVLVWR
remove the condenser support.
5HPRYHWKHVFUHZQXWV¿[LQJIDQEODGHZLWKVSDQQHU
to remove the fan blade.
5HPRYHWKHWDSSLQJVFUHZV¿[LQJPRWRUSXOORXWWKH
pin of leading wire for motor and remove the screws
¿[LQJPRWRUVXSSRUWDQGFKDVVLVWRUHPRYHWKHPRWRU
and motor support sub-assy.
9.Remove axial fan blade
10.Remove motor and motor support sub-assy
8.Remove condenser support
condenser support
axial fan blade
motor
motor support sub-assy
