Technical Information
Service Manual
Model GWH09AGA-K6DNA1A GWH12AGB-K6DNA1A
Product Code CB385001000/CB385001002 CB385001700/CB385001702
Power
Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity W 2500 3200
Heating Capacity W 2800 3400
Cooling Power Input W 720 991
Heating Power Input W 750 916
Cooling Power Current A 3.2 4.4
Heating Power Current A 3.2 4
Rated Input W 1500 1500
Rated Current A 6 6
Rated Heating Current A 7.5 7.5
Air Flow Volume(SS/H/MH/M/ML/L/SL) m
3
/h 500/470/430/390/320/270/250 590/520/480/400/350/320/280
Dehumidifying Volume L/h 0.6 1.4
EER W/W 3.47 3.23
COP W/W 3.73 3.71
SEER W/W 6.5 6.1
SCOP(Average/Warmer/Colder) 4/5.1/- 4/5.1/-
HSPF / /
Application Area m
2
10-16 15-22
Indoor Unit
Indoor Unit Model GWH09AGA-K6DNA1A/I GWH12AGB-K6DNA1A/I
Indoor Unit Product Code CB385N01000/CB385N01002 CB385N01700/CB385N01702
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) mm Ф93X505 Ф93X633.5
Fan Motor Cooling Speed(SS/H/MH/M/ML/L/SL) r/min 1300/1200/1120/1050/920/800/750 1350/1200/1120/1050/950/850/750
Fan Motor Heating Speed(SS/H/MH/M/ML/L/SL) r/min 1300/1200/1120/1050/950/850/800 1350/1200/1120/1050/990/920/850
Output of Fan Motor W 20 20
Fan Motor RLA A 0.22 0.22
Fan Motor Capacitor μF 1 1
Input of Heater W / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ5 Φ5
Row-n Gap mm 2-1.4 2-1.4
Coil Length (LXDXW) mm 509X22.8X266.7 584X22.8X266.7
Swing Motor Model MP24AK/MP24BA/MP24HF MP24AK/MP24BA/MP24HF
Output of Swing Motor W 1.5/1.5/1.5 1.5/1.5/1.5
Fuse A 3.15 3.15
Sound Pressure Level(SS/H/MH/M/ML/L/SL) dB (A)
Cooling:38/36/34/32/28/25/24
Heating:37/36/34/33/30/26/25
Cooling:41/37/35/33/30/26/24
Heating:41/37/35/33/31/28/25
Sound Power Level(SS/H/MH/M/ML/L/SL) dB (A)
Cooling:55/48/46/44/40/37/36
Heating:49/48/46/45/42/38/37
Cooling:56/49/47/45/42/38/36
Heating:53/49/47/45/43/40/37
Dimension (WXHXD) mm 704X260X185 779X260X185
Dimension of Carton Box (LXWXH) mm 748X316X247 823X316X247
Dimension of Package (LXWXH) mm 753X332X258 828X332X258
Net Weight kg 7.5 8
Gross Weight kg 9 9.5
2. Specications
2.1 Specication Sheet

Gree PULAR Series Specifications

General

Refrigerant	R32
Type	Split System
Cooling Capacity	9000 - 36000 BTU/h
Heating Capacity	9000 - 36000 BTU/h
Power Supply	220-240V, 50Hz
Features	Wi-Fi Control, Self-Cleaning, Turbo Mode, Sleep Mode
Indoor Unit Dimensions	Varies by model
Outdoor Unit Dimensions	Varies by model
Indoor Unit Weight	Varies by model
Outdoor Unit Weight	Varies by model
Energy Efficiency Ratio (Cooling)	3.5 - 4.0
Energy Efficiency Ratio (Heating)	3.8 - 4.2
