Technical Information
Service Manual
Model GWH18AGD-K6DNA1A GWH09AGB-K6DNA1B
Product Code CB385001900 CB385002300
Power
Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity W 4600 2700
Heating Capacity W 5200 2800
Cooling Power Input W 1355 735
Heating Power Input W 1340 695
Cooling Power Current A 6 3.51
Heating Power Current A 5.8 3.32
Rated Input W 1800 1500
Rated Current A 9 6
Rated Heating Current A 9 7.5
Air Flow Volume(SS/H/MH/M/ML/L/SL) m
3
/h 910/850/780/740/700/650/610 550/520/480/400/340/310/280
Dehumidifying Volume L/h 1.4 1.4
EER W/W 3.39 3.67
COP W/W 3.88 4.03
SEER W/W 6.6 6.6
SCOP(Average/Warmer/Colder) 4/5.1/- 4.2/5.2/-
HSPF / /
Application Area m
2
23-34 10-16
Indoor Unit
Indoor Unit Model GWH18AGD-K6DNA1A/I GWH09AGB-K6DNA1B/I
Indoor Unit Product Code CB385N01900 CB385N02300
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) mm Ф106X739 Ф93X580
Fan Motor Cooling Speed(SS/H/MH/M/ML/L/SL) r/min 1230/1050/980/900/850/800/750 1300/1200/1120/1050/920/800/750
Fan Motor Heating Speed(SS/H/MH/M/ML/L/SL) r/min 1200/1050/980/900/850/800/750 1300/1200/1120/1050/950/850/800
Output of Fan Motor W 35 20
Fan Motor RLA A 0.45 0.22
Fan Motor Capacitor μF 2.5 1
Input of Heater W / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ5 Φ5
Row-n Gap mm 2-1.3 2-1.4
Coil Length (LXDXW) mm 745X22.8X342.9 584X22.8X266.7
Swing Motor Model MP24BA/MP24AK/MP24HF MP24BA/MP24AK/MP24HF
Output of Swing Motor W 1.5/1.5 /1.5 1.5/1.5/1.5
Fuse A 3.15 3.15
Sound Pressure Level(SS/H/MH/M/ML/L/SL) dB (A)
Cooling:42/38/35/33/31/29/28
Heating:43/40/37/34/32/30/29
Cooling:40/37/35/33/29/26/21
Heating:39/36/34/32/29/25/24
Sound Power Level(SS/H/MH/M/ML/L/SL) dB (A)
Cooling:58/51/49/46/43/41/38
Heating:55/52/49/46/44/42/41
Cooling:55/49/47/45/41/37/34
Heating:53/48/46/44/41/38/35
Dimension (WXHXD) mm 982X311X221 779X260X185
Dimension of Carton Box (LXWXH) mm 1039X377X287 823X316X247
Dimension of Package (LXWXH) mm 1044X385X297 828X332X258
Net Weight kg 13.5 8
Gross Weight kg 16.5 9.5
