Gree PULAR Series

7
Technical Information
Service Manual
Model GWH12AGC-K6DNA1A GWH24AGD-K6DNA1A
Product Code CB385002400 CB385001500
Power
Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity W 3200 6200
Heating Capacity W 3400 6500
Cooling Power Input W 933 1631
Heating Power Input W 872 1645
Cooling Power Current A 4.15 7.5
Heating Power Current A 3.86 7.6
Rated Input W 1500 2200
Rated Current A 6 9.3
Rated Heating Current A 7.5 9.7
Air Flow Volume(SS/H/MH/M/ML/L/SL) m
3
/h 680/620/560/490/450/420/390 1050/950/800/750/700/650/600
Dehumidifying Volume L/h 1.4 1.8
EER W/W 3.43 3.80
COP W/W 3.90 3.95
SEER W/W 6.5 /
SCOP(Average/Warmer/Colder) 4.1/5.1/- 4.3/5.3/-
HSPF / /
Application Area m
2
15-22 23-34
Indoor Unit
Indoor Unit Model GWH12AGC-K6DNA1A/I GWH24AGD-K6DNA1A/I
Indoor Unit Product Code CB385N02400 CB385N01500
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) mm Ф98X630 Φ106X739
Fan Motor Cooling Speed(SS/H/MH/M/ML/L/SL) r/min 1300/1150/1100/1000 /950/850/750 1370/1200/1100/1000/920/850/750
Fan Motor Heating Speed(SS/H/MH/M/ML/L/SL) r/min 1250/1100/1050/1000/950/850/800 1370/1200/1120/1050/980/900/850
Output of Fan Motor W 20 50
Fan Motor RLA A 0.30 0.24
Fan Motor Capacitor μF 1.5 /
Input of Heater W / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ5 Φ7
Row-n Gap mm 2-1.4 2-1.4
Coil Length (LXDXW) mm 634X22.8X304.8 745X22.8X342.9
Swing Motor Model MP24BA/MP24AK/MP24HF MP24BA
/
MP24AK/MP24HF
Output of Swing Motor W 1.5/1.5/1.5 1.5/1.5/1.5
Fuse A 3.15 3.15
Sound Pressure Level(SS/H/MH/M/ML/L/SL) dB (A)
Cooling:41/37/35/33/31/27/22
Heating:41/36/34/32/30/27/25
Cooling:46/42/40/38/36/32/25
Heating:49/44/42/40/36/32/29
Sound Power Level(SS/H/MH/M/ML/L/SL) dB (A)
Cooling:57/50/48/46/43/39/36
Heating:55/49/47/45/43/40/37
Cooling:63/59/57/55/53/49/42
Heating:63/58/56/54/50/46/43
Dimension (WXHXD) mm 825X293X196 982X311X221
Dimension of Carton Box (LXWXH) mm 870X349X257 1039X377X287
Dimension of Package (LXWXH) mm 875X365X268 1044X385X297
Net Weight kg 10 13.5
Gross Weight kg 12 16
