Gree R1 - Page 17

Service Manual
Technical Information
14
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Indoor side
Fan Type Centrifugal Centrifugal
Diameter Length(DXL) mm Φ205.5X111 Φ205.5X111
Input of Heater W / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Row-n Gap mm 3-1.3 3-1.3
Coil Length (LXHXW) mm 330X38.1X324 330X38.1X324
Swing Motor Model MP24VA MP24VA
Output of Swing Motor W 1.5 1.5
Fuse A 3.15 3.15
Sound Pressure Level (H/M/L) dB (A) 50/48/46 50/48/46
Sound Power Level (H/M/L) dB (A) 60/58/56 60/58/56
Outdoor
side
Compressor Manufacturer/Trademark
ZHUHAI LANDA COMPRESSOR
CO., LTD
ZHUHAI LANDA COMPRESSOR
CO., LTD
Compressor Model QXF-B098C190 QXF-B098C190
Compressor Oil FW68DA or equivalent FW68DA or equivalent
Compressor Type Rotary Rotary
L.R.A. A 21.5 21.5
Compressor RLA A 3.2 3.2
Compressor Power Input W 686 686
Overload Protector HPA-422 HPA-422
Throttling Method Capillary Capillary
Operation Temp ºC 16~30 16~30
Ambient temp (Cooling) ºC 18~43 18~43
Ambient temp (Heating) ºC / -7~30
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ5 Φ7
Rows-n Gap mm 2-1.3 2-1.4
Coil Length (LXHXW) mm 612X22.8X342.9 611X25.4X342.9
Fan Type Axial-ow Axial-ow
Fan Diameter mm Φ353 Φ353
Sound Pressure Level (H/M/L) dB (A) 57/55/53 57/55/53
Sound Power Level (H/M/L) dB (A) 67/65/63 67/65/63
Defrosting Method / /
