Gree R1 - Page 19

Service Manual
Technical Information
16
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Indoor side
Fan Type Centrifugal Centrifugal
Diameter Length(DXL) mm Φ205.5X111 Φ197.6X111
Input of Heater W / 100
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Row-n Gap mm 3-1.3 4-1.6
Coil Length (LXHXW) mm 330X38.1X324 400X50.8X381
Swing Motor Model MP24VA SM020B
Output of Swing Motor W 1.5 4
Fuse A 3.15 /
Sound Pressure Level (H/M/L) dB (A) 50/48/46 50/48/46
Sound Power Level (H/M/L) dB (A) 60/58/56 60/58/56
Outdoor
side
Compressor Manufacturer/Trademark
ZHUHAI LANDA COMPRESSOR
CO., LTD
ZHUHAI LANDA COMPRESSOR
CO., LTD
Compressor Model QXF-B098C190 QXF-B133E090
Compressor Oil FW68DA or equivalent FW68DA
Compressor Type Rotary Rotary
L.R.A. A 21.5 27.5
Compressor RLA A 3.2 4.4
Compressor Power Input W 686 955
Overload Protector HPA-422 HPA-325
Throttling Method Capillary Capillary
Operation Temp ºC 16~30 16~30
Ambient temp (Cooling) ºC 18~43 18~43
Ambient temp (Heating) ºC -7~30 -7~30
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Rows-n Gap mm 2-1.4 2-1.3
Coil Length (LXHXW) mm 611X25.4X342.9 685X25.4X400
Fan Type Axial-ow Axial-ow
Fan Diameter mm Φ353 Φ391
Sound Pressure Level (H/M/L) dB (A) 57/55/53 60/58/56
Sound Power Level (H/M/L) dB (A) 67/65/63 70/68/66
Defrosting Method / /
