Service Manual
Technical Information
4
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Indoor side
Fan Type Centrifugal Centrifugal
Diameter Length(DXL) mm Φ205X109.5 Φ197.6X111
Input of Heater W 190 100
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Row-n Gap mm 3-1.3 3-1.3
Coil Length (LXHXW) mm 401X38.1X381 401X38.1X381
Swing Motor Model SM020B SM020B
Output of Swing Motor W 4 4
Fuse A / /
Sound Pressure Level (H/M/L) dB (A) 55/53/51 50/48/46
Sound Power Level (H/M/L) dB (A) 65/63/61 60/58/56
Outdoor
side
Compressor Manufacturer/Trademark
ZHUHAI LANDA COMPRESSOR
CO., LTD
ZHUHAI LANDA COMPRESSOR
CO., LTD
Compressor Model QXF-D184F090AA QXF-B133E090
Compressor Oil FW68DA FW68DA
Compressor Type Rotary Rotary
L.R.A. A 41 27.5
Compressor RLA A 5.84 4.4
Compressor Power Input W 1320 955
Overload Protector UP3-B7 HPA-325
Throttling Method Capillary Capillary
Operation Temp ºC 16~30 16~30
Ambient temp (Cooling) ºC 18~43 18~43
Ambient temp (Heating) ºC / /
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ5 Φ5
Rows-n Gap mm 3-1.3 2-1.3
Coil Length (LXHXW) mm 839X34.2X400.05 688X22.8X400.05
Fan Type Axial-ow Axial-ow
Fan Diameter mm Φ396 Φ391
Sound Pressure Level (H/M/L) dB (A) 63/60/57 60/58/56
Sound Power Level (H/M/L) dB (A) 72/69/66 70/68/66
Defrosting Method / /
