OUTDOOR UNIT INSTALLATION
Outdoor Unit Dimensions
Model ABCDE
SAP09HP230V1AO
21.7 14.9 23.5 13.9
(551) (378) (597) (353)
SAP12HP230V1AO
21.7 14.9 23.5 13.9
(551) (378) (597) (353)
SAP18HP230V1AO
24.0 16.8 31.1 14.6
(610) (427) (790) (370)
SAP24HP230V1AO
24.0 16.8 31.1 14.6
(610) (427) (790) (370)
35.4
(899)
35.4
(899)
38.6
(980)
38.6
(980)
OUTDOOR UNIT DIMENSIONS in (mm)
A
D
B
D
C
E
A
