Air-to-water Heat Pump Split Versati
19
SPLIT
TYPE
7.2 Space requirements for installation
Wall
Wall
Service Space
7.3 Installation process of indoor unit
Step1:Drill holes on the wall in the following drawing.
Wall
Wall
Step2:Install expansion bolts and forecasted pannel.
Wall
Anchor bolt X3
Mounting
bracket
