Green Power CC5000-LPG - Power Panel List

6
Power Panel List
No. Power panel Electrical element on control
panel
Applicable
Type
Remark
A. Gas Inlet B. Circuit Breaker C. Ground Terminal D. AC Overload Protector E. AC Voltmeter F. AC Receptacle G. DC Overload Protector
1
H. 12V DC Receptacle
CC1200
Single Voltage (Single-phase) without Hour Meter(recoil)
A. AC Overload Protector B. DC Overload Protector C. Receptacle D. Power Indicator
2
E. 12V DC Receptacle
CC1200 Single Voltage
(Single-phase ǃ recoil) for portable type
A. Gas Inlet B. Keyed Ignition C. Circuit Protector D. AC Volt Meter E. Ground Terminal F. Circuit Breaker G. AC Receptacle H. AC Receptacle I. Hour Meter J. DC Overload Protector K. DC Red Terminal
3
L. DC Black Terminal
CC3000 CC4000 CC5000
Single Voltage (Single-phase) with Hour Meter ˄Electric Starter˅
A
B
C
D
E
A
B
C
EF
D
G
H
A
B
C
D
E
F
G
H
I
J
K
L
