Electric Air-Conditioning Unit Green GT790 12.000BTU 24V - DS540059
Electric Air-Conditioning Unit Green GT790 12.000BTU 12V - DS630051
Electric Air-Conditioning Unit Green GT790 12.000BTU 24V - DS540059
Electric Air-Conditioning Unit Green GT790 12.000BTU 12V - DS630051
MAIN COMPONENTS OF
THE AIR-CONDITIONING
SYSTEM
CONTROLLING
AND BOARD
FUNCTIONS
Internal part
Evaporator Unit
External part
Condenser Unit
1. 2.
Air inlet
Air outlet
Air inlet
Air outlet
Size: 460 x 160 x 320mm Size: 660 x 490 x 210mm
Display
Display
• On/Off
- Press to turn on and off.
• Temperature Configuration
- Press “TEMPERATURE” to adjust tempera-
ture after you turned on the Unit;
- Now, press “TEMPERATURE” again for
(DOWN) or “SPEED” for (UP) to adjust
temperature (12°C-32°C).
• Speed Configuration
- Press “SPEED” to define the speed after you
turned on the System;
- Now, press “TEMPERATURE” again for
(DOWN) or “SPEED” for (UP) to adjust
speed (8 speeds).
• Tension Configuration
- Press “ON/OFF” three times to access the
tension adjustment, press “TEMPERA-
TURE” again for (DOWN) or “SPEED” for
(UP) to adjust tension.
• Clear Failures
- Failures are removed when the unit is
restarted.
Remote Control
• On/Off
- Press to turn on and off.
• Temp + / -
- Controls the temperature.
• Speed + / -
- Controls the speed.
• 26 °C
- Adjusts to 26 °C.
• Strong
- Increases to maximum power.
• Standard
- Standard performance.
• Sleep
- Economical mode.
*
Remote control battery, not included
