Insert three ⅞” x 3” x 20¼” table/shelf
rails (part 7) into table support of back
panel. Insert eleven ⅞” x 3” x 20¼”
table/shelf rails (part 7) into shelf
support of back panel. Insert two
1½” x 4” x 20¼” side rails (part 6) into
back right and back left post. Insert
free ends of all rails into
corresponding holes of front panel.
Using ¾” kappet screws, screw
together potting bench. Be sure that
all parts are fully inserted into posts
before securing. Snap
kappet screw caps
over screw heads.
Lay out three ½” x 5½” x 43” table top
rails (part 12). Using 1¼” kappet
screws, insert screws through two
⅞” x 1½” x 16½” table brace (part 13).
Fasten screws to screw pilot holes of
the three table top rails. Using
PVC glue can, apply glue to
inner edges of 16½” table top
end cap (part 14). Slide end
cap onto ends of table top.
Using a file or sandpaper, file
sharp corners of end cap.
5
6
7
