General Description - NOT model specificEnergy Recovery Ventilator with Heating and Cooling
6
Unit Dimensions and Weights
Unit Installation
Model
Overall Exterior Dimensions
Approximate
Weight
(lbs)
Configuration Length Width Height
Exhaust
Hood
Outdoor Air
Hood
ERCH-20
Heating Only 76.2
54.3 54.2 20.8 17.7
1550
Cooling Coil* 96.2 1825
WSHP 2375
Evap Cooling 1800
ERCH-45
Heating Only 84.3
64.4 70.2 20.7 21.7
2325
Cooling Coil* 104.3 2725
WSHP 3775
Evap Cooling 2900
ERCH-55
Heating Only 97.5
75.2 71 23.6 21.7
3000
Cooling Coil* 116.5 3475
WSHP 4725
Evap Cooling 3325
ERCH-90
Heating Only 109.5
94.5 89 25.5 26.7
4300
Cooling Coil* 129.5 5050
WSHP 6450
Evap Cooling 5400
*With or without heat.
WSHP = Water-Source Heat Pump
All dimensions are in inches. Unit weights assume rooftop configuration with weatherhood, filters, outdoor air damper and
heating or cooling options (where applicable). The approximate weight (lbs) is assuming all possible accessories are added
per housing and may vary by 10% depending on unit.
