Greenheck G Series User Manual

11
Downblast Centrifugal Roof Exhaust Fans
Birdguard
Curb Cap/
Venturi
Shock
Mounts
Shroud
Wheel
Motor Cover
Motor
Shroud Brace
Vertical
Support
Lower
Windband
Hood Clip
Motor Cover
Belt
Motor Pulley
Motor
Fan Shaft
Birdguard
Shroud Brace
Curb Cap/
Venturi
Windband
Wheel
Shaft Pulley
Drive Frame
Assembly
Conduit
Chase
Shock Mounts
Shroud
Vertical
Support
Bearings
G Direct Drive Centrifugal Roof Exhaust Fan
GB Belt Drive Centrifugal Roof Exhaust Fan
Parts List
NOTE: Each fan bears a manufacturer’s
nameplate with model number and serial
number embossed. This information
will assist the local representative and
the factory in providing service and
replacement parts. Before taking any
corrective action, make certain unit is not
capable of operation during repairs.
®

Greenheck G Series Specifications

General

Housing Material	Galvanized Steel
Motor	TEFC
Type	Centrifugal
Mounting	Wall
Wheel Type	Backward Inclined
Construction	Heavy Duty
Horsepower Range	0.5 - 100 HP
Options	Sound Attenuators, Variable Frequency Drive
