5878 • 5880 • 5882
17
Accuracy
Accuracy is specified as follows: ± (a percentage of the reading + a fixed amount)
at 20 °C to 26 °C (68 °F to 78.8 °F), 45% to 55% relative humidity.
Accuracy Table
*Capacitance between 0 and 5 µF in parallel to resistance can add ± (10% + 1 d) additional
error.
Insulation Resistance Test
Range Open Circuit Voltage Test Current Short Circuit Current
250 V < 300 V ≥ 1 mA for R ≤ 250 kΩ
500 V < 600 V ≥ 1 mA for R ≤ 500 kΩ≤ 3 mA
1000 V < 1200 V ≥ 1 mA for R ≤ 1 MΩ
Value Range Accuracy Notes
AC Test
399.9 V
300 kΩ
600 V
Input Impedance
Insulation
39.99 MΩ± (3 % + 0.05 MΩ)
Resistance* 399.9 MΩ± (3 % + 0.2 MΩ)
Testing
2.000 GΩ± (3 % + 0.002 GΩ)
Open Circuit Voltage:
Continuity 0.00 to 20.00 Ω± (3 % + 0.01 Ω) 7 V to 9 V
Test Current: 200 mA
399.9 Ω± (3 % + 0.5 Ω)
Resistance*
3999 Ω± (3 % + 5 Ω)
Open Circuit Voltage:
39.99 kΩ± (3 % + 0.01 kΩ)
7 V to 9 V
399.9 kΩ± (3 % + 0.1 kΩ)
Timer (Model 5882 only)
Range Resolution Accuracy
0:00 to 15:00 min 1 s 2%
