773 and 774 Ratchet Cable Cutters
Greenlee / A Textron Company 7 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
Maintenance
General
Maintain the tool with care. Keep the blades sharp
and the tool clean for better and safer performance.
Follow instructions for lubricating the cutter; lubrication
prolongs the tool life and enables the tool to cut with
less force. Keep grips dry, clean and free from oil and
grease.
Note: The blade pivot lock nut (23) may require tighten-
ing after making several initial cuts on a new or repaired
unit. Always maintain proper adjustment on all pivot
screws. For adjustment procedures, see Assembly—
Tighten pivot screws.
Cleaning the cutter
Blow dirt and/or cable particles out of the ratchet
mechanism with compressed air.
Lubricating the cutter
Close the blades and apply Molykote lubricant or
equivalent between the blades. Lubricate the teeth on
holding pawl (6) and drive pawl (7). Lubricate the four
pivot shoulder screws (13, 16 and 17) and area between
pivoting surfaces. Operate the cutter to spread the
lubricant.
Disassemble, clean, and lubricate the tool if it does not
operate smoothly.
Wear eye protection when using this
tool. Failure to wear eye protection
could result in serious eye injury
from ying debris.
Pinch points:
Keep hands away from moving
parts.
Keep hands away from closing
blades.
Lubrication points
—use Molykote
®
