Greenlee 847 - Parts List

Greenlee Textron / Subsidiary of Textron Inc.
11
4455 Boeing Dr., Rockford, IL 61109-2988 815/397-7070
PVC Heaters for PVC Conduit
1 503 0908.0 Heating element ................................................................1
2 503 0890.4 Cover Unit, Long................................................................1
3 503 0891.2 Cover Unit, Short ............................................................... 1
4 905 3295.3 Catch .................................................................................2
5 905 3305.4 Keeper ...............................................................................2
6 905 3300.3 Handle, Plastic, 3/8 – 16 x 1.37 x 4.375 ........................ 2
7 905 0506.9 Washer, Lock, .388 x .673 x .070 Steel............................. 2
8 905 0639.1 Nut, Hex 3/8 – 16 Regular Full ..........................................2
9 905 0717.7 Screw, Machine #10 – 24 x .500 Round Head ................12
10 905 0750.9 Washer, Lock, .200 x .373 x .023 Internal Tooth.............16
11 503 0901.3 Clamp, heating element.....................................................2
12 503 0982.0 Reflector ............................................................................1
14 503 0903.0 Shaft, .312 x 70.0 Roller ....................................................2
15 905 1773.3 Retaining Ring, .312 Truarc #5100-S-PP .......................... 4
16 905 3292.9 Bearing, Bronze, .314 x .377 x .375 ..................................6
17 503 0902.1 Aluminum Roller ................................................................6
18 905 2400.4 Screw, Set, 1/4 – 20 x .250 Socket ...................................6
20 905 3296.1 Wheel, 5.75 x 1.50.............................................................2
21 503 0907.2 Axle....................................................................................1
22 503 0898.0 Axle Bracket ......................................................................1
23 905 2265.6 Retainer, push-on ..............................................................2
24 503 0875.0 Control Box........................................................................1
25 503 0905.6 Cover, Control Box ............................................................1
26 503 0904.8 Spacer, .218 x .500 x .375.................................................4
27 503 0877.7 Power Cord Unit ................................................................1
28 918 6093.8 Plug ...................................................................................1
29 918 6091.1 Pilot Light...........................................................................1
30 918 6090.3 Switch ................................................................................1
31 503 0879.3 Wire Unit, Switch ...............................................................2
32 503 0878.5 Wire Unit, Pilot Light ..........................................................2
33 905 3288.0 Timer .................................................................................1
34 905 3290.2 Knob ..................................................................................1
35 905 3289.9 Plate ..................................................................................1
36 503 0876.9 † Motor Unit ..........................................................................1
37 905 3285.6 † Drive Sprocket ...................................................................3
38 503 0971.4 † Idler Sprocket ....................................................................1
39 905 3291.0 † Shoulder Bolt, .310 x .500 x 1/4 – 20 ................................1
40 503 0909.9 † Drive Chain (includes item 41) ..........................................1
41 905 3311.9 † Master Link ........................................................................1
42 503 0974.9 Guard Unit, Chain..............................................................1
43 905 0704.5 † Screw, Machine, #10 – 32 x 3/8 Round Head ................... 4
44 905 3468.9 † Washer, Flat, #10 ..............................................................4
45 905 1533.1 Screw, Machine, #10 – 24 x 1.500 Round Head ............... 2
46 905 3293.7 Screw, Machine, #10 – 24 x 1.00 Slotted Round Head..... 4
47 918 5885.2 Grip, Cord ..........................................................................1
† Model 848 Only
Decals and Conversion Kit:
502 8005.8 Decal, Hot Warning ...........................................................1
503 0973.0 Decal, Instruction...............................................................1
503 0392.9 Decal, Damp Warning .......................................................1
503 1089.5 Tag, Attach Handle............................................................2
503 1092.5 Conversion Kit (Convert an 847 into an 848; includes all items marked with †)
Parts List
