*d refers to the least significant digit (the number in the right-most position)
**Sensitivity: Volts > 1 V; Amps > 5 A
Minimum Input Frequency: 10 Hz
† Maximums: 600 V, 2000 Amps
Power Factor: 0.2 to 1.0
††Accuracy specified for crest factor less than 4
Accuracy
Accuracy is specified as follows: ± (a percentage of the reading + a fixed amount) at 18 °C to
28 °C (64.4 °F to 82.4 °F).
Accuracy Table
Value Measurement Range Accuracy
**Frequency
50/60 Hz ± (2 d)*
10 Hz to 1000 Hz ± (1.5% + 2 d)*
0 to 99.99 KW ± (2% + 0.05 KW)
†True Power (AC or DC) 100 to 999.9 KW ± (2% + 0.5 KW)
1000 to 1200 KW ± (2% + 5 KW)
0 to 99.99 KW ± (2% + 0.05 KW)
†KVAR (AC or DC) 100 to 999.9 KW ± (2% + 0.5 KW)
1000 to 1200 KW ± (2% + 5 KW)
at O Hz and 50/60 Hz at 40 Hz to 400 Hz
††Voltage (AC or DC) at
0 to 499.9 V ± (1.5% + 0.5 V) ± (2.0% + 0.5 V)
10 mΩ Input Impedance
500 to 600 V ± (1.5% + 5 V) ± (2.0% + 5 V)
0 to 199.9 A ± (1.5% + 0.5 A) ± (2.0% + 0.5 A)
††Current (AC or DC) 200 to 499.9 A ± (2.0% + 0.5 A) ± (2.5% + 0.5 A)
500 to 2000 A ± (2.0% + 5 A) ± (2.5% + 5 A)
