CR25 Cable Roller Guide
Operating Tips
Cable Bundling
Apply cable ties loosely
and at random intervals.
Do not overtighten
cable ties.
25
Cable Stretching
Avoid stretching
the cable.
Do not exceed 25 lb.
of pulling tension.
Cable Bend
Radius
Cable Diameter = 0.20"
Minimum Bend Radius
Maintain a maximum
bend radius of 4 times
the cable diameter
(4-pair cables).
Never exceed
a 90° bend.
