CS-2072
Troubleshooting
Situation Probable Causes Solutions
No indication, i.e., The breaker for that Scan the box that supplies that
no green LED circuit is not in the circuit.
and buzzer. box being scanned.
Multiple indications The first scan was Scan again, moving the receiver
on second scan. performed too slowly. Be sure to keep the nose
quickly. of the receiver close to the
breaker and maintain proper
orientation.
Tracing circuit — Use an outlet adapter. Screw the
connected to light adapter into the socket, and then
fixture. plug the transmitter into it.
Or plug an extension cord into the
adapter, and then plug the
transmitter into the extension cord.
Specifications
Operating Conditions:
Temperature: 5 °C to 40 °C (41 °F to 104 °F)
Relative Humidity (non-condensing): 80% maximum for temperatures up to
31 °C (88 °F), decreasing linearly to 50% maximum at 40 °C (104 °F)
Altitude: 2000 m (6500') maximum
Indoor use only.
Storage Conditions:
Temperature: –29 °C to 66 °C (–20 °F to 150 °F)
Relative Humidity: 0% to 80% (non-condensing)
Remove battery from receiver.
Snap the transmitter and receiver together to store.
Transmitter Only
Voltage Range: 110–120 VAC, 60 Hz
Wattage: 3.0 W maximum
For use with NEMA 1-15R outlets or light socket adapter
Measurement Category: Category II, 120 V per UL 61010-1 (transmitter only)
Receiver Only
Battery: 9 V (NEDA 1604, JIS 006P, or IEC 6F22)
Battery Life: Approximately 50 hours with alkaline battery
