Fig. 5

STARTUP

1. Before each startup,make sure the power switch is in the OFF position

2. Place air compressor on a at,level surface.

3. Release pressure from the system. Drain moisture from the air tank by slowly opening the

air tank drain valve by turning clockwise.Once all the moisture has drained out, close the

tting securely.

4. Turn the pressure regulator knob fully counterclockwise to close airow from air outlet

port.

5. Attach air hose and accessories.

6. Turn the compressor ON by moving the switch to the AUTO/ON position and allow the

tank pressure to build.Once the air pressure reaches the maximum preset pressure(“cut-

out “pressure) it will automatically shut off.

7. Slowly turn the pressure regulator knob clockwise to open airow from air outlet port until

desired output pressure is reached.

WARNING

OPERATION

NOTE: Air tank will not pressurize while drain valve is open.

NOTE: The air compressor will automatically restart once the pressure in the air tank

drops below the minimum preset pressure ( "cut-in" pressure).

Too much air pressure causes a hazardous risk of bursting. Check the manufacturer’s maximum

pressure rating for air tools and accessories.The regulator outlet pressure must never exceed the

maximum pressure rating.

AIR TANK PRESSURE

GAUGE

TOOL OUTLET

PRESSURE GAUGE

OPEN
