GreenWorks LMC420 User Manual

1 DESCRIPTION
1.1 PURPOSE
This machine is used for domestic lawn mowing. The
cutting blade must be approximately parallel to the
ground. All four wheels must touch the ground while
mowing.
1.2 OVERVIEW
Figure 1~13
1
Start button
2
Start handle
3
Self-propel drive lever
4
Upper handle
5
Lower handle
6
Grass catcher
7
Rear discharge flap
8
Height adjustment lever
9
Battery compartment flap
10
Mulch plug
11
Side discharge chute
12
Handle hole
13
Handle bolt
14
Handle nut
15
Handle pin
16
Grass catcher handle
17
Grass catcher hook
18
Door rod
19
Side discharge flap
20
Pivot
21
Safety key
22
Battery pack
23
Battery capacity indicator
24
Self-propel speed control
25
Blade bolt
26
Spacer
27
Blade
28
Battery release button
29
Turbo button
30
Headlight
31
Rubber edge guard
2 SAFETY
WARNING
Make sure that you follow all safety instructions.
Refer to Safety Manual.
3 INSTALLATION
WARNING
Do not use accessories that are not recommended by
the manufacturer.
WARNING
Do not put in the safety key or the battery pack until
you finalised the assembly of all the parts.
3.1 UNPACK THE MACHINE
WARNING
Make sure that you correctly assemble the machine
before use.
WARNING
• If parts of the machine are damaged, do not use
the machine.
• If you do not have all the parts, do not operate the
machine.
• If parts are damaged or missing, contact the
service center.
1. Open the package.
2. Read the documentation provided in the box.
3. Remove all the unassembled parts from the box.
4. Remove the machine from the box.
5. Discard the box and packing material in compliance
with local regulations.
3.2 UNPACKING AND HANDLE
ASSEMBLY
Figure 2
1. Place the mower upright in vertical position.
2. Remove the packing material from the cable.
3. Remove the rubber edge guard from the upper
handle.
4. Insert the upper handle into the lower handle.
5. Put the bolts through the holes and tighten with the
nuts.
WARNING
Do not damage the cable while installing the upper
handle.
3.3 UNFOLD THE LOWER HANDLE
Figure 3
1. Pull up on the handle holes to release the lower
handles.
4
English
EN
