2. Fold the lower handle up until the handle pins lock
into position.
NOTE
Make sure that the two handle pins are in the same
position.
3.4 INSTALL THE GRASS CATCHER
Figure 4
1. Remove the mulch plug.
2. Remove the side discharge chute.
3. Open the rear discharge flap and hold it.
4. Hold the the grass catcher by its handle and engage
the hooks on the door rod.
5. Close the rear discharge flap.
3.5 INSTALL THE MULCH PLUG
Figure 5
1. Remove the grass catcher.
2. Open the rear discharge flap and hold it.
3. Hold the mulch plug by its handle and fit it in the
discharge chute.
4. Close the rear discharge flap.
3.6 INSTALL THE SIDE DISCHARGE
CHUTE
Figure 6
CAUTION
When you use the side discharge chute,
• Do not install the grass catcher.
• Keep the mulch plug installed.
1. Open the side discharge flap and hold it.
2. Line up the recesses of the side discharge chute
below the pivot.
3. Close the side discharge flap.
3.7 SET THE BLADE/CUTTING
HEIGHT
The machine can be set to different blade/cutting
heights.
Figure 7
1. Pull the height adjustment lever rearward to
increase the blade/cutting height.
2. Push the height adjustment lever forward to
decrease the blade/cutting height.
3.8 INSTALL THE BATTERY PACK
Figure 8.
WARNING
• If the battery pack or charger is damaged, replace
the battery pack or the charger.
• Stop the machine and wait until the engine stops
before you install or remove the battery pack.
• Read, know, and do the instructions in the battery
and charger manual.
NOTE
The machine has an automatic switch function that
lets the other battery work when the first cannot
operate.
1. Open the battery compartment flap.
2. Align the lift ribs on the battery pack with the
grooves in the battery compartment.
3. Push the battery pack into the battery compartment
until the battery pack locks into place.
4. When you hear a click, the battery pack is installed.
5. Close the battery compartment.
NOTE
The engine starts only when you put in the safety key.
3.9 INSTALL THE BATTERY PACK
Figure 8.
WARNING
• If the battery pack or charger is damaged, replace
the battery pack or the charger.
• Stop the machine and wait until the engine stops
before you install or remove the battery pack.
• Read, know, and do the instructions in the battery
and charger manual.
NOTE
The machine has an automatic switch function that
lets the other battery work when the first cannot
operate.
1. Open the battery compartment flap.
2. Align the lift ribs on the battery pack with the
grooves in the battery compartment.
3. Push the battery pack into the battery compartment
until the battery pack locks into place.
4. When you hear a click, the battery pack is installed.
5. Close the battery compartment.
NOTE
The engine starts only when you put in the safety key.
