13 32202390 4 Bolt
14 32204113D 4 Screw
15 311021179 1 Front wheel axle
16 33307470A 4 Axle press plate
17 32204113D 8 Screw
18 341281179A 2 8” Wheel assembly
19 341021179B 1 Front panel
20 3220343 2 Nut
21 333011546 1 Height adjustment link bar
22 32243563 4 Nut
23 332011179 1 Height adjustment tension spring
24 341011179B 1 Rear baffle
25 3220951D 7 Screw
26 333041519 1 Height adjustment bracket (left)
27 3221637 4 Bolt
28 341251179 1 Rear cover
29 32910131 4 Nut
30 312011560 2 Mechanical vertical switch assembly
31 342031179 2 Rubber plug
32 333031560 1 Height adjustment bracket (right)
33 3290506 2 Clip washer
34 332021179 1 Rear cover axle
35 332111179 1 Torsinal spring (rear cover)
36 33401222 1 Torsinal spring
37 3290135 1 Cotter pin
38 311011179 1 Rear wheel axle
39 342011179 1 Rear shield
40 3220505D 4 Screw
41 332041179 1 Press board (rear shield)
42 341271179A 2 10” Wheel assembly
43 332061179 2 Pin
44 341151546 2 Knob
45 332051179 2 Spring
46 332071179A 2 Limit column
47 332081179A 2 Block
48 311302338 1 Height adjustment bar assembly
49 32201467 2 Nut
50 332101179A 2 Washer
51 322031179 2 Bolt
