ASSEMBLY INSTRUCTIONS
Fig. 2
14
Handle knob
Handle knob
UNFOLDING AND ADJUSTING HANDLE (See Figure 2)
• Pull up and back on the upper handle to raise the handle into operating position. Make certain
the handles snap into place securely.
• Tighten the upper handle with the cam locks on both sides.
• Tighten the lower handle with the handle knobs on both sides.
Cam locks
