PARTS LIST
ITEM NO. PART NO. DESCRIPTION QTY
1 333071161 Front wheel axle 1
2 3220537 Self-lock nut M6 2
3 3330384 Wave-shaped ring 4
4
3320639 Rubber wheel washer 2
5 31102488-5 7” wheel 2
6 3290135 Split pin 5
7 3220898 Washer 4
8 34106488-5 Wheel cover 4
9 322011163 Screws 4
10 31103488A 10” wheel 2
11 3320237 Rubber wheel washer B 2
12 33303227-7 Link bar 1
13 31102222 Rear wheel axle 1
14 3340137-2 Spring 1
15 33313250-2 Blade 1
16 3221037A Nut M10x1.25 1
17 3331435A Square block 1
18 3410535 Blade insulator 1
19 311082325 Catcher bag assembly 1
20 33302222-1 Height adjustment bracket (left) 1
21 32201235D Screw M6x8 4
22 3320238A Spindle bushing 1
23 32208261 Nut 4
24 3410237A Fan 1
25 3420436 Spring cover 3
26 33304235 Rear cover spring (left) 1
27 34104236 Mulching plug 1
28
34106236 Rear bafe 1
29 34103236-5 Rear cover 1
30 33302235 Rear cover spring (right) 1
