ASSEMBLY INSTRUCTIONS
Fig. 5
2
1
INSTALLING SIDE DISCHARGE CHUTE (See Figure 5)
• Lift the side discharge cover (1).
• Align the grooves on the deector (2) with the pins on the underside of the cover.
• Lower the deector until the hooks on the mower deck are secured in the openings in the
deector.
• Release the deector and cover.
