2. Remove the two blade-fastening screws located on both sides of the mounting screw.
3. Remove the mounting screw and spacer with a 5/8 Inch (15mm) wrench or socket.
4. Carefully detach the blade(s) and fan.
5. Inspect the fan, blade bolt, and base for any damage.
6. Examine the motor shaft to ensure it is not bent or damaged.
Install the New Blades
NOTE:The blade configuration of this mower is customizable. Dual blades provide the best cutting
performance, while single blade offers extended runtime.
1. Reinstall the fan, followed by the new blade(s) (Dual blade: upper blade followed by mulching blade) positioning
the angled ends of the mulching blade(jagged) upward toward the cutting cover.
*Dual blade order: Install upper blade (flat) then mulching blade (jagged edges)
*Single blade order: Install the mulching blade (jagged edges) only
2. Ensure that the three keyed holes on the blade(s) align with the three holes on the fan.
16
