Translation of the original instructions
TECHNICAL SPECIFICATIONS 3500 AND 11HRG
ENGINES
- HONDA GX200 OHV, 196 cm³ 5,5HP (@3600 r.p.m.) one-cylinder, petrol.
- KOHLER 3000 OHV, 196 cm³ 5,5HP (@3600 r.p.m.) one-cylinder, petrol.
- GR200, 196 cm³ 5,5HP (@3600 r.p.m.) one-cylinder, petrol.
STARTER: recoil starter.
FUEL TANK: 3,1 L (GX200) – 3,6 L (3000) – 3 L (GR200)
CLUTCH: conic and active.
TRANSMISSION: with gears in oil bath.
GEARBOX: 2 forward gears + 1 reverse (3500) – 3 forward gears + 1 reverse (11HRG)
PTO:
1) one direct PTO running at the engine r.p.m. in anti-clockwise rotation (11UNI 221)
2) one synchronized P.T.O with gearbox speeds in clockwise rotation (13 UNI 221).
HANDLEBAR: height-and side adjustable.
WORKING WIDTH without side discs: adjustable at 58-85-111 cm (with enlargement kit).
ROTARY TILLER RPM: I 53 r.p.m.; II 123 r.p.m.; III 162 r.p.m.(for 11HRG only); I REV 53 r.p.m..
ATTACHMENTS: furrower, wheel extensions, rubber wheels, transfer wheel, plough.
WEIGHT: 79 kg with GX200 - 81 kg with 3000 and GR200
TECHNICAL SPECIFICATIONS 11500
ENGINES
- ROBIN EX27 265 cm³ 8,3HP (@3600 r.p.m.) one-cylinder petrol.
- GR300 302 cm³ 9,3HP (@3600 r.p.m.) one-cylinder petrol.
- KOHLER KD15 350 349 cm³ 7,5HP (@3600 r.p.m.), one cylinder diesel.
STARTER: recoil starter (electric starter available for diesel engine only).
FUEL TANK: 6,1 L (EX27) – 5,5 L (GR300) - 4,3 L (15LD350).
CLUTCH: conic and active.
TRANSMISSION: oil bath gears.
GEARBOX: 3 forward gears + 1 reverse gear.
PTO:
1) one direct PTO running at the engine r.p.m. in anti-clockwise rotation (11UNI 221)
2) one synchronized P.T.O with gearbox speeds in clockwise rotation (13 UNI 221).
HANDLEBAR: height and side- adjustable and fitted on anti-vibration blocks.
WORKING WIDTH without side discs: adjustable at 59-86-112 cm (with extensions kit).
ROTARY TILLER R.P.M.: I 53 r.p.m.; II 123 r.p.m.; III 162 r.p.m.; I REVERSE 53 r.p.m..
ATTACHMENTS: plough, furrower, wheel extensions, rubber wheels, transfer wheels, plough.
WEIGHT: 90 kg (EX27) - 92 kg (GR300) - 121 kg (KD15 350 AE)
