Grillo 3500 - Technical Specifications

2500-3500/ Translation of the original instructions
TECHNICAL SPECIFICATIONS 2500
ENGINE:
- ROBIN SUBARU EX17, 169 cm³, 5HP @ 3600 r.p.m., one cylinder petrol.
- HONDA GX160 OHV, 163 cm³, 4,8 HP @ 3600 r.p.m., one cylinder petrol.
- KOHLER 3000, 196 cm³, 5,5 HP @ 3600 r.p.m, one cylinder petrol.
STARTER: recoil starter
FUEL TANK: 3,1 litres (GX160) – 3,6 (EX17 - 3000)
HOURLY CONSUMPTION: 1,4 litres (GX160) – 1,5 litres (EX17) – 1,7 (3000)
CLUTCH: conic and active clutch
TRANSMISSION: with gears in oil bath
GEARBOX: two forward gears
HANDLEBAR: height-and side adjustable
STANDARD ROTARY TILLER: with 4 tines and side discs for a total width of 620 mm
HOES DIAMETRE: 330 mm
WORKING AREA without side discs: adjustable at 580 – 850 mm (with enlargement kit)
WORKING AREA DEPTH: 320 mm
ROTARY TILLER RPM: I 53 r.p.m.; II 123 r.p.m.
ATTACHMENTS: furrower, wheel extensions, rubber wheels, transfer wheel, plough.
WEIGHT: with GX160 kg 72 – with 3000 kg 75 – with EX17 kg 74
TECHNICAL SPECIFICATIONS 3500
ENGINE:
- ROBIN SUBARU EX17, 169 cm³, 5HP @ 3600 r.p.m., one cylinder petrol.
- HONDA GX160 OHV, 163 cm³, 4,8 HP @ 3600 r.p.m., one cylinder petrol.
- KOHLER 3000, 196 cm³, 5,5 HP @ 3600 r.p.m., one cylinder petrol.
- LOMBARDINI 15LD225, 224 cm³, 4,8 HP @ 3600 r.p.m., one cylinder, diesel.
STARTER: recoil starter.
FUEL TANK: 3,1 litres (GX160) – 3,6 (EX17 – 3000) – 3 litres (15LD225)
HOURLY CONSUMPTION: 1,4 litres (GX160) – 1,5 litres (EX17) – 1,7 (3000) – 1 litre (15LD225)
CLUTCH: conic and active clutch
TRANSMISSION: with gears in oil bath
GEARBOX: two forward gears and one reverse gear.
HANDLEBAR: height-and side adjustable
STANDARD ROTARY TILLER: with 6 tines and side discs for a total width of 990 mm
HOES DIAMETRE: 330 mm
WORKING AREA without side discs: adjustable at 580 – 850 – 1110 mm (with enlargement kit)
WORKING AREA DEPTH: 320 mm
ROTARY TILLER RPM: I 53 r.p.m.; II 123 r.p.m.; I REV 53 r.p.m.
ATTACHMENTS: furrower, wheel extensions, rubber wheels, transfer wheel, plough.
WEIGHT: with GX160 kg 78 – with 3000 kg 81 – with EX17 kg 80 – with 15LD225 kg 93
