Translation of the Original Instructions
ORDERING SPARE PARTS
Always state the machine serial number and the code number of the part to be replaced. Contact
your local dealer. Our address is:
GRILLO S.p.A.
Via Cervese 1701 - 47521 CESENA (FC) - ITALY
Tel. 0039 / 0547 / 633111 - Fax 0039 / 0547 / 632011
Web site: www.grillospa.it - E-mail: grillo@grillospa.it
TECHNICAL SPECIFICATIONS G110
ENGINE
LOMBARDINI 15LD440 with electric starter
HONDA GX390
MACHINE:
Clutch: active clutch.
Gearbox: 6 speeds – 3 forward + 3 reverse both as rotavator and as sickle-bar (turning the
handlebars).
Speeds in km/h with engine at 3600 r.p.m. are as follows:
Gears Speeds with tyres 5.00-10
Ist
IInd
IIIrd
Ist REVERSE
IInd REVERSE
IIIrd REVERSE
1,3
2,4
5,0
0,7
1,5
3,2
P.T.O.: independent from the gearbox, 965 rpm with engine at 3600 rpm.
Wheels: tyres 4.00-10, 5.00-10 (5.00-12 only with furrower and plough). Garden wheels 20×10.00-
8
Rotary tiller: 68 cm standard and adjustable up to 33-47-58-68 cm.
Handlebar: Side and height adjustment – reversible.
Track external measurements: with tyres 5.00-10 57 cm – with wide steel wheels 36-44 cm.
Implements and attachments: 110/115/117/127 central cutter bar, plough, furrower, driven trailer
150×110 cm, cage wheels, tow bar, all purpose flail 68-85 cm, rotary cutter 75 cm, snow thrower
70 cm, orientable brush 100 cm, orientable front blade 125 cm, power harrow 50 cm, rotary plough
30 cm, wheel snow chains.
TECHNICAL SPECIFICATIONS G108
ENGINES
LOMBARDINI 15LD350
HONDA GX270
MACHINE:
Clutch: active clutch.
Gearbox: 6 speeds – 3 forward + 3 reverse both as rotavator and as sickle-bar (turning the
handlebars). Speeds in km/h with engine at 3600 r.p.m. are as follows:
8
