7
SPARE PARTS
Always use original spare parts, as they are the only ones to offer complete safety and interchangeability.
Always state the serial number when ordering. For engine parts, refer to the specific handbook.
WARRANTY
The warranty conditions are as indicated on the specific warranty card.
The engine warranty conditions are those of its manufacturer.
WE ADVISE YOU TO KEEP THE FOLLOWING SPARE PARTS TO HAND
For the rotovator:
2 throttle cables
2 clutch cables
1 throttle lever
1 clutch lever
5 right-hand tiller blades with screws
5 left-hand tiller blades with screws.
For the mower bar:
5 mower bar fingers
3 blades
10 nails for single blades
1 complete blade
10 screws for fingers
2 blade couplings.
ORDERING SPARE PARTS
Always state the machine serial number and the code number of the part to be replaced.
Contact your local dealer. For more information:
GRILLO S.p.A. - Via Cervese 1701 - 47023 CESENA (FC) - ITALY
Tel. 0039 / 0547 / 633111 - Fax 0039 / 0547 / 632011 - Web site: www.grillospa.it - E-mail: grillo@grillospa.it
TECHNICAL DATA
ENGINE TYPES:
LOMBARDINI LGA 226
LOMBARDINI 15LD 225
ROBIN EX17
YANMAR L48
MACHINE:
Clutch: Dry, manual.
Gearbox: 5 speeds as a rotovator, 3 forward + 2 reverse.
4 speeds as a motor mower (turning the handlebars), 2 forward + 2 reverse.
Speeds in kmph with engine at 3600 rpm are as follows:
P.T.O.: independent from the gearbox; 965 rpm with engine at 3600 rpm.
Wheels: tyres 4.00-8 - 16-6.50/8.
Rotary tiller: 58 cm standard; adjustable up to 37-50 cm.
Handlebar: Side and height adjustment - reversible.
Track: external measurements:
with tyres 4.00-8, 43 cm
with wide steel wheels, 36-44 cm
Implements and attachments: tiller, mower bar, snow thrower, plough, furrower, grass shredder, riding sulky,
towed trailer, rotary tiller support wheel, towing bar, wheel weights, metal wheels, container trailer.
Gears Speeds with tyres 4.00-8
Iª 1,1
IIª 2,6
IIIª 11,4
Iª RM 1,1
IIª RM 2,6
