GF2 - Translation of the Original Instructions
IDENTIFICATION AND SERVICING
IDENTIFICATION
The machine’s serial number is punched on the
nameplate on the left-hand longitudinal member
of the chassis and on the gearbox nameplate.
Always state the serial number when ordering
spare parts.
AFTER-SALES SERVICE
This handbook provides instructions for use of the cultivator and for correct basic servicing which
the user can carry out personally. For all procedures not described in this manual, contact your
local dealer.
SPARE PARTS
Always use original spare parts, as they are the only ones to offer complete safety and
interchangeability. Always state the serial number when ordering. For engine parts, refer to the
specific manual.
WARRANTY
The guarantee is given in compliance with the current law. The Grillo dealer will supply the client
with a copy of the registration card of the machine, which they will print from the Grillo website. For
the engine, the guarantee of the relative manufacturers apply.
ORDERING SPARE PARTS
Always state the machine serial number and the code number of the part to be replaced. Contact
your local dealer. Our address is:
GRILLO S.p.A.
Via Cervese 1701 - 47521 CESENA (FC) - ITALY
Tel. 0039 / 0547 / 633111 - Fax 0039 / 0547 / 632011
Web site: www.grillospa.it - E-mail: grillo@grillospa.it
TECHNICAL SPECIFICATIONS
ENGINE TYPES:
- EX 17 ROBIN SUBARU (petrol)
- GX160 HONDA (petrol)
- GX200 HONDA (petrol)
- KOHLER 3000 (petrol)
- LONCIN G200 (petrol)
MACHINE:
Clutch: conic active clutch.
Gearbox: 6 speeds – 3 forward gears and 3 reverse gears
Speeds in km/h with engine at 3600 r.p.m. are as follows:
Gears Speeds with tyres 4.00-8
1
st
2
nd
3
rd
1
st
reverse
2
nd
reverse
3
rd
reverse
1,0
2,0
3,0
1,0
2,0
3,0
7
