No. Description QTY No Code QTY
1 Hood 1 2 Temperature gauge 1
3 Hood screw 2 4 Hood handle 1
5 Hood buer 4 6 Warming rack 1
7 Grillstream grill 190mm 4 8 Grillstream griddle 220mm 1
9 Flame tamer 3 10 Burner clip 3
11 Main burner 3 12 Fireplace back seal plate 1
13 Grease cup bracket 1 14 Grease cup 1
15 Grease tray 1 16 Side burner lid axis 1
17 Side burner lid 1 18 Side Burner Trivet 1
19 Side burner assembly 1 20 Side burner base 1
21 Side burner connection strap 1 22 Side burner ignition wire 1
23 Side burner injector 1 24 Side Burner Hose Assembly 1
25 Side burner side shelf 1 26 Side shelf 1
27 Side shelf decoration strip 2 28 Left side panel 1
29 Door magnet 1 30 Front Support Bar 1
31 Back panel 1 32 Bottom panel 1
33 Right side panel 1 34 Battery box 1
35 Door spindle 2 36 Door stopper 2
37 Bottom panel decoration strip 1 38 Trolley Corner Brace 2
39 Caster Fixing Plug 4 40 Castor 4
41 LED switch 1 42 LED connection wire 1
43 LED light panel
4 44 Knob bezel 4
45 Control knob 4 46 Control panel right decoration 1
47 Control panel left decoration 1 48 Door hinge 2
49 Control panel board 1 50 Gas connection adaptor 1
51 Gas connection xation 1 52 Gas corrugated pipe 3
53 Gas tube 1 54 Main burner gas valve 3
55 Side burner gas valve 1 56 Inner control panel 1
57 Fat channel 1 58 Control panel left reinforce bar 1
59 Control panel right reinforce bar 1 60 Bottle opener 1
61 Fat cup 1 62 Door 2
