Page 12
Fittings
NOTE: ALL HARDWARE IS DRAWN IN FULL SCALE TO HELP IDENTIFY EACH
PART
M6 Captive Nut
Door Hinge
Tools required (not supplied)
Cross Head Screwdriver (Philips) Spanner
Prepare frame for assembly
Lift hood, remove & unpackage all items except burners & burner assembly.
Proceed to step 1
M4x8 ScrewM6x12 ScrewM4x12 Screw
Door Stopper
x 2 x 44
x 4 x 2
Metal Washer
x 6 x 6 x 40
Plastic Spacer
x 4
x 2
x 4
Door Stop Screw
Door Handle Screw
GSG66SS
To Next Page
