COMPRESSOR PARTS LIST - PUMP
REF NO. DESCRIPTION QTY. PART#
1 CYLINDER HEAD 1 PACP408
2 ALLEN BOLT 4 PACP396
3 SPRING WASHER 10 PACP3
4 AIR FILTER 1 PACP409
5 FILTER ELEMENT 1 PACP410
6 CYLINDER HEAD GASKET 1 PACP9
7 IN. & EX. VALVE ASSEMBLY 1 PACP82
8 VALVE SEAT GASKET 1 PACP411
9 CYLINDER 1 PACP412
10 HEXAGON NUT 2 PACP20
11 SPRING WASHER 2 PACP21
12 DOUBLE HEAD SCREW 2 PACP22
13 CYLINDER GASKET 1 PACP14
14 PISTON RING SET 1 PACP413
15 PISTON SET 1 PACP414
16 ROD 1 PACP415
17 CRANKSHAFT & BALANCER 1 PACP416
18 MOTOR SET 1 PACP417
19 FRONT COVER GASKET 1 PACP418
20 FRONT COVER 1 PACP419
21 BOLT 4 PACP27
22 BOLT 1 PACP420
23 O-RING 1 PACP421
24 DIPSTICK SET 1 PACP24
25 DIPSTICK GASKET 1 PACP25
26 COOLING FAN 1 PACP422
27 SHROUD 1 PACP423
28 HEXAGON BOLT SET 4 PACP424
29 PLATE WASHER 4 PACP124
30 HEXAGON BOLT SET 4 PACP425
31 STARTING CAPACITOR 1 PACP426
32 RUNNING CAPACITOR 1 PACP427
33 CIRCUIT BREAKER 1 PACP67
34 EXHAUST ELBOW 1 PACP428
