14
COMPRESSOR PARTS LIST - TANK/FRAME
REF NO. DESCRIPTION QTY. PART#
35 AIR TANK 1 PACP429
36 TANK WHEEL 2 PACP430
37 TANK WHEEL BOLT 2 PACP431
38 RUBBER PAD 2 PACP432
39 PLATE WASHER 2 PACP45
40 HEXAGON BOLT 2 PACP42
41 DRAIN VALVE 1 PACP35
42 GRIP SET 1 PACP433
43 CHECK VALVE 1 PACP434
44 TUBE 1 PACP435
45 UNLOADING ELBOW 1 PACP48
46 UNLOADING TUBE 1 PACP436
47 PRESSURE SWITCH 1 PACP437
48 PRESSURE RELIEF VALVE 1 PACP438
49 EXHAUST ELBOW 1 PACP439
50 TUBE 1 PACP440
51 REGULATOR 1 PACP388
52 PRESSURE GAUGE 2 PACP441
53 ELBOW 1 PACP190
54 PLUG 2 PACP56
55 CABLE 1 PACP442
56 POWER CABLE 1 PACP336
57 PANEL 1 PACP443
58 HANDLE BUSHING 2 PACP444
59 BOLT 16 PACP396
60 BODY SEAT 1 PACP445
61 HEXAGON BOLT SET 2 PACP446
62 AUTO RELIEF VALVE 1 PACP447
63 STRAIN RELIEF BUSHING 1 PACP383
64 STRAIN RELIEF BUSHING 1 PACP63
65 STRAIN RELIEF BUSHING 1 PACP337
66 QUICK COUPLER 2 PACP448
To Next Page
