REF PART # DESCRIPTION REF PART # DESCRIPTION
506 PFB01M FLANGE BOLT M6-1 X 12 519 PH81910519 LEVER SHAFT GASKET
507 PH81910507 OIL PUMP COVER 520 PH81910520 BEARING
508 PH81910508 O-RING 34.5 X 1.8 521 PH81910521 FORK LEVER ASSEMBLY
509 PH81910509 OIP PUMP ASSEMBLY 522 PH81910522 WASHER
510 PH81910510 PIN 3 X 6 523 PH81910523 FUEL CONTROLLER PARTS
511 PH81910511 FLANGE BOLT M9 X 14 524 PH81910524 HANDLE BRACKET ASSEMBLY
512 PH81910512 OIL FILTER CLEANING ELEMENT 525 PH81910525 SPEED CONTROL LEVER
513 PH81910513 SEALING RING 20 X 2.65 526 PH81910526 FLANGE BOLT M6-1 X 14
514 PH81910514 OIL GUIDE 527 PH81910527 FLANGE BOLT M6-1 X 18
515 PH81910515 OIL PUMP DRIVING GEAR 528 PH81910528 LEAD SEAL
516 PH81910516 FLY BLOCK PIN 529 PH81910529 RETURN SPRING 2
517 PH81910517 FLY BLOCK 530 PH81910530 RETURN SPRING 1
518 PH81910518 GOVERNER FORK TAPPET 531 PH81910531 SPEED CONTROL SPRING
