Grizzly CLAMP RACK User Manual

CLAMP RACK
CUT SHEET
©Copyright Grizzly Industrial, Inc., 2020
END PANEL
24
5
/8" x 48"
END PANEL
24
5
/8" x 48"
12
3
/8"
2 x 4 x 96"
(45° CUTS)
FOR PANEL
BASE FRAME
2 x 4 x 96"
FOR TOP BRACES
AND LEDGERS
48" x 96" x ¾"
PLYWOOD
48" x 96" x ¾"
PLYWOOD
12
3
/8" 12
3
/8" 12
3
/8"
SIDE PANEL
24
3
/8" x 48"
SIDE PANEL
24
3
/8" x 48"
SHELF
12
3
/8" x 24
3
/8"
BASE
24
5
/8" x 36"
BASE
24
5
/8" x 36"
12
3
/8"
12
3
/8"
24
3
/8"
24
3
/8"
