Grizzly G0937 - Wiring Diagram

19
2 3
OUT
DC
110V
GAN L1 L2 A- At K1 K2
P1 P2 P3
K3 K4
SQ
RP
SA2
SA1
SB
FU
HL
N-L
L-1
IN
AC
N L
100-120V
50-60Hz
8 9
X4
X3
M2
Bk Wt
X3
M1
Wt Bk
7 6
PE-2
PE-1
PE
Name
Choose Switch
Change Switch
Limit Switch
Fuse
Power Indicator Light
Item No.
SA1
SA2
SQ
FU
HL
Name
PC Board
Lathe Motor
Mill Head Motor
Potentiometer
Emergency Stop Switch
Item No.
XMT-1115
M1
M2
RP
SB
XMT-1115
WIRING DIAGRAM
