H5502 Benchtop Bending System -5-
The Model H5502 Benchtop Bending System
was carefully packed before it left our warehouse.
If you discover the equipment is damaged after
you have signed for delivery,
please immediately
call Customer Service at (570) 546-9663 for
advice.
Save the containers and all packing materials for
possible inspection by the carrier or its agent.
Otherwise, filing a freight claim can be difficult.
When you are completely satisfied with the con-
dition of your shipment, you should inventory its
parts.
The purpose of this section is to guide you
through the required steps to get your machine
out of its packaging and into operating condition.
Unpacking and
Clean-Up
Inspection
About this Section
SECTION 4: SET UP
Remove the box from around the Model H5502
Benchtop Bending System (
Figure 1). There will
be a total of three tools and a bag of handles.
Wear safety glasses dur-
ing the entire setup
process!
This equipment pre-
sents serious injury haz-
ards to untrained users.
Read through this entire
manual to become famil-
iar with the operating
procedures before using
this equipment!
1. Bending Tool Assembly ..............................1
2. Twist Tool Assembly ..................................1
3. Scroll Tool Assembly ..................................1
4. Handle and Hardware Bag
—Twist Tool Handles..................................4
—Scroll Tool Handles ................................4
—Hex Wrenches 8mm, 10mm....................2
Figure 1. The three main tools with the handle
and hardware bag.
3
4
1
2
